我觉得在前端开发中过多地考虑算法没有太多实际的意义。但这仅仅是我觉得,我并没有证据证明这一点。那为何不来尝试一下,面对一个特定的任务,我将使用不同的算法来实现,看看究竟效率相差多少。今天我想通过字符串搜索这一场景来进行测试。
测试场景
-
主字符串就以 ABC 的一篇文章内容为例,略做修改
There are some times when clicking “like” on a friend’s Facebook status doesn’t feel appropriate. A bad day. A loved one lost. A break up. It only seems natural that a “dislike” button could solve the conundrum of wanting to empathize but not seem inappropriate by clicking “like.” Mark Zuckerberg Puts the Rest of Us to Shame by Speaking Fluent Chinese. Mark Zuckerberg: Facebook Founder and Animal Butcher. Mark Zuckerberg and That Shirt. The idea has been on Mark Zuckerberg’s radar for a while, he said. In 2010, he told ABC News’ Diane Sawyer that that Facebook would “definitely think about” adding a dislike button. “People definitely seem to want it,” Zuckerberg said. Four years later — Zuckerberg says Facebook is still “thinking about” adding the oft-requested button, Zuckerberg says Facebook is still “thinking about” adding the oft-requested button. At a town hall meeting on Thursday, the CEO revealed he has some reservations about the feature. “There are two things that it can mean,” Zuckerberg said of the potential button, which could be used in a mean spirited way or to express empathy. Finding how to limit it to the latter is the challenge. Zuckerberg said he doesn’t want the button to turn into a “voting mechanism” or something that isn’t “socially valuable.” “Often people will tell us they don’t feel comfortable pressing ‘like,’” Zuckerberg said. “What’s the right way to make it so people can easier express a wide range of emotions?” One suggestion percolating online: Roll out the feature under a different name. However, an “empathy button” just may not have the same ring to it as “dislike.”
-
模式字符串
- 靠近起点
friend
- 靠近终点
button
- 靠近中间
Zuckerberg says Facebook is still "thinking about" adding the oft-requested button.
- 靠近起点
暴力算法
首先是最原始的做法,主串左侧开始,逐个对比,如果不相同,则主串起始点向后移一位,重复,直到找到。
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
1 | 2 | 3 | 4 | ||||||||||||||||||||
G | C | A | G | A | G | A | G |
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
1 | |||||||||||||||||||||||
G | C | A | G | A | G | A | G |
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
1 | |||||||||||||||||||||||
G | C | A | G | A | G | A | G |
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
1 | |||||||||||||||||||||||
G | C | A | G | A | G | A | G |
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
1 | |||||||||||||||||||||||
G | C | A | G | A | G | A | G |
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | ||||||||||||||||
G | C | A | G | A | G | A | G |
以上示例(http://igm.univ-mlv.fr/~lecroq/string/examples/exp3.html)说明了一次暴力搜索的过程。
我用 JS 模拟了这个算法:
const mainString = '';
const searchString = '';
function basicSearch(mainStr, str, offset) {
const mainLength = mainStr.length;
const searchLength = str.length;
if (searchLength > mainLength - offset) {
return -1;
}
offset = offset || 0;
for (let i = 0; searchlength > i; i++) {
if (str.charAt(i) !== mainString.charAt(offset + i)) {
return basicSearch(mainStr, str, offset + 1);
}
}
return offset;
}
basicSearch(mainString, searchString);
递归版
function basicSearchLoop(mainStr, str) {
const mainLength = mainStr.length;
const searchLength = str.length;
for (let padding = mainLength - searchLength, offset = 0; offset <= padding; offset++) {
let match = true;
for (let i = 0; i < searchLength; i++) {
if (str.charAt(i) !== mainString.charAt(offset + i)) {
match = false;
break;
}
}
if (match)
return offset;
}
return -1;
}
非递归版
KMP 算法(Knuth-Morris-Pratt 算法)
KMP 算是字符串搜索算法里的明星。不过本文重点不是介绍算法历史,有兴趣的可以移步百度百科(KMP 算法)。这里一样先看一个例子:
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
1 | 2 | 3 | 4 | ||||||||||||||||||||
G | C | A | G | A | G | A | G |
移动步数:4 ()
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
1 | |||||||||||||||||||||||
G | C | A | G | A | G | A | G |
移动步数:1 ()
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | ||||||||||||||||
G | C | A | G | A | G | A | G |
移动步数:7 ()
如果每次发生不一致都要计算一次效率太低,可以考虑将计算结果缓存到一张部分匹配表中(也可以在搜索之前先生成此表)。以 intristed 为例:移动步数:1 ()
原始示例出处。我们看到,这里有一个 kmpNext
数组,这是什么呢?我们慢慢来理解。每一次尝试匹配时,从模式字符串的左端开始对比,如果第 i 个字符相同,则比较第 i+1 个;如果不相同,则需要把模式字符串向右移动。移动的位数是算法优劣的关键。每次移动一位是暴力算法的做法。kmp 算法有自己独特的移动步数计算方法。
首先引入两个概念:前缀和后缀。
- 前缀:一个字符串所有头部的集合,不包含自身;
- 后缀:一个字符串所有尾部的集合,不包含自身。
我们看下面的例子(编号从 1 开始编):
i | n | t | r | i | s | t | i | n | g |
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | |
i | n | t | r | i | s | t | e | d |
在模式串 8 的位置发生了不匹配,那么要计算模式串右移的位数之前,我们先写出位置 1~7 处的子串 intrist 的前缀和后缀:
- 前缀:i, in, int, intr, intri, intris, intrist
- 后缀:t, st, ist, rist, trist, ntrist, intrist
我们再定义一个部分匹配值的概念:前缀和后缀交集中,长度最长的元素的长度。很显然,这里前缀和后缀没有交集,最长共同元素的长度也就认为是 0,那么模式串向右移动(8-0=)8 个字符。跟上面的算法(上面是 7-(-1))稍有不同,不过大体意思一样,计算结果也一样。
模式字符串 | i | n | t | r | i | s | t | e | d |
---|---|---|---|---|---|---|---|---|---|
序号 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 |
部分匹配值 | 0 | 1 | 0 |
计算右移位数就可以很容易地从表中计算出来:
移动位数=已匹配的位数-已匹配部分的部分匹配值
例如在第 6 个位置 s 处发现不匹配,那么需要右移 5-1=4 位。
但这样计算其实并不方便,比如已匹配位数为 0 的情况很难处理,所以我们可以对部分匹配值做一个修正,每个值减去 1,公式也相应调整为:
移动位数=不匹配字符的位置-已匹配部分的修正部分匹配值
这样这个公式就与上面示例中的公式相同了。
我用 JS 模拟了这个算法:
function KMPSearch(mainLength, str, offset, group) {
var mainLength = mainString.length;
const searchLength = str.length;
if (searchLength > mainLength - offset) {
return -1;
}
offset = offset || 0;
group = group || [1, 1];
const searchedString = [];
for (let i = 0; searchlength > i; i++) {
const searchingChar = str.charAt(i);
if (searchingChar !== mainString.charAt(offset + i)) {
var offsetJump;
if (group[i]) {
offsetJump = group[i];
}
else {
offsetJump = next(searchedString);
group[i] = offsetJump;
}
return KPMSearch(mainLength, str, offset + offsetJump, group);
}
searchedString.push(searchingChar);
}
return offset;
}
function next(chars) {
const length = chars.length;
for (let i = length - 1; i > 0; i--) {
let isMatch = true;
for (let j = 0; j <= i; j++) {
if (chars[j] !== chars[length - i + j]) {
isMatch = false;
break;
}
}
if (isMatch)
return length - i;
}
return length;
}
递归版
function KMPSearchLoop(mainStr, str) {
const mainLength = mainString.length;
const searchLength = str.length;
for (let padding = mainLength - searchLength, group = [1, 1], offset = 0; offset <= padding;) {
const searchedString = [];
let match = true;
var offsetJump;
for (let i = 0; i < searchLength; i++) {
const searchingChar = str.charAt(i);
if (searchingChar !== mainString.charAt(offset + i)) {
match = false;
if (group[i]) {
offsetJump = group[i];
}
else {
offsetJump = next(searchedString);
group[i] = offsetJump;
}
break;
}
searchedString.push(searchingChar);
}
if (match) {
return offset;
}
else {
offset += offsetJump;
}
}
return -1;
}
非递归版
Horspool 算法
Horspool 算法在做匹配的时候,创造性地从右向左匹配,对后来其他算法有很深的影响。还是那句话,本文会讲很多算法上的东西,但本文重点不是算法,下面还是会过一下 Horspool 算法的搜索过程,如果难以理解,还是参考其他更详细的资料。依然是示例(http://igm.univ-mlv.fr/~lecroq/string/examples/exp18.html):
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
1 | |||||||||||||||||||||||
G | C | A | G | A | G | A | G |
移动步数:1 (Horspool[A])
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
3 | 2 | 1 | |||||||||||||||||||||
G | C | A | G | A | G | A | G |
移动步数:2 (Horspool[G])
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
5 | 4 | 3 | 2 | 1 | |||||||||||||||||||
G | C | A | G | A | G | A | G |
移动步数:2 (Horspool[G])
G | C | A | T | C | G | C | A | G | A | G | A | G | T | A | T | A | C | A | G | T | A | C | G |
8 | 7 | 6 | 5 | 4 | 3 | 2 | 1 | ||||||||||||||||
G | C | A | G | A | G | A | G |
先对齐,从模式串的右侧开始匹配,如果完全匹配则结束搜索,否则查看模式串最右边对应的主串字符是什么。找出这个字符在模式串中最后出现的位置(除最末位)距离模式串最后一个字符的距离,如果没有在模式串中出现过,则认为这个距离是模式串的长度。我们可以事先把这个距离表计算出来。
7 | 6 | 5 | 4 | 3 | 2 | 1 | |
G | C | A | G | A | G | A | G |
⇒
字符 | G | C | A | *(其他) |
距离 | 2 | 6 | 1 | 8(模式串的长度) |
以上面第三次尝试为例,从右向左匹配了 5 次后发现匹配失败了,那么这时就看序号 1 处主串的字符是什么。很容易得到是 ‘G’,查询上表,‘G’ 对应的距离是 2,那就很简单粗暴地把模式串向右移动两位,再次进行匹配。
上代码:
function HorspoolSearchLoop(mainString, str) {
var mainLength = mainString.length;
var searchLength = str.length;
var table = {};
for (var index = 0, l = searchLength - 1; l > index; index++;){
table[str.charAt(index)] = l - index;
}
for (var offset = 0, padding = mainLength - searchLength; offset <= padding;) {
var rightChar;
var match = true;
var offsetJump;
for (var i = searchLength - 1; i >= 0; i--) {
var searchingChar = str.charAt(i);
if (i === searchLength - 1) {
rightChar = mainString.charAt(offset + i);
}
if (searchingChar !== mainString.charAt(offset + i)) {
match = false;
offsetJump = table[rightChar] || searchLength;
break;
}
}
if (match) {
return offset;
}
else {
offset += offsetJump;
}
}
return -1;
}
这次只写了非递归的版本,因为递归的版本已经没有写的必要。
还是来谈 javascript
冲着 javascript 性能来看这篇文章的同学一定没有兴趣看上来的算法。我一边写一边测试,终于也不愿意再深究其他的一些算法,原本还想把 Boyer-Moore 算法、Sunday 算法也一起讨论讨论,现在看来完全没有必要。为什么?因为 javascript 实现这些算法的效率实在太!慢!了!
javascript 代码的性能确实不高,相比较于循环,递归更是慢了近 1 倍。javascript 在分配内存,数组访问,函数调用等等方面的性能与编译型语言差距很大。如果要实现一个特定的任务,我们更多地应该考虑尽可能地使用原生代码来实现,高级的算法在 javascript 里似乎并没有多少实用价值。
